Code: EQD-ORG2

Earthquaker Devices Organizer Polyphonic Organ Emulator

In stock

$319.00 incl GST

The Organizer is a polyphonic organ emulator designed to mimic the organ tones of yesteryear crossed with the highly unique “Guitorgan”.

In stock

Payment Options: Master card, Visa, American Express and PayPal logo

The Organizer is a polyphonic organ emulator designed to mimic the
organ tones of yesteryear crossed with the highly unique “Guitorgan”.
The organizer has a warm and very analog  feel with a hint of Leslie
warble that is unlike other modern  octave shifters. It tracks all over
the neck on both guitar and  bass and will transpose single notes as
well as chords. The  Organizer uses a mix of analog and DSP circuitry
with true bypass switching and an all analog direct (dry) signal path.

Controls
Up: Level control for the octave up.
Down: Level control for the octave down.
Choir: This control takes a mix of the octave up and octave
down setting and regenerates it. The end result is an additional 2
octaves up, 2 octaves down and direct signal with a slight delay that
adds a “church organ” like feel. This control only works if the octave
up and octave down are in use.
Direct: Level control for the analog dry signal.
Tone: Low pass filter for the wet signal, counter clockwise rolls off the high end.
Lag: Delay control for the wet signal. Full counter clockwise is minimal delay, delay time increases as it rotates clockwise.

Power
A standard 9 volt DC power supply with a negative centre 2.1mm barrel, current draw is 70ma. No battery option.

Measures
4 5/8″ x 2 1/2″ x 2.25″ with knobs

Notes
The Organizer has an output gain stage with no master control.
When it’s idle, even with all knobs at zero, the will be about as much
“white noise” as an average overdrive pedal with it’s gain at zero and
the level set to unity. A minimal amount while idle is normal but it
will not be noticeable during play. The sound will be more apparent in
front of a gained up amp or other dirt/gain/boost pedals.

Switching
This device is true bypass and uses electronic relay-based switching. Audio will not pass without power.

Power
This device takes a standard 9 volt DC power supply with a 2.1mm negative centre barrel. We always recommend pedal-specific, transformer-isolated wall-wart power supplies or multiple isolated-output supplies. Pedals will make extra noise if there is ripple or unclean power. Switching-type power supplies, daisy chains and non-pedal specific power supplies do not filter dirty power as well and let through unwanted noise. DO NOT RUN AT HIGHER VOLTAGES!Dimensions: 4.75 x 2.50 x 2.25 in. (121 x 64 x 57 mm) with knobs
Current Draw: 81 mA
Input Impedance: 1 MΩ
Output Impedance: 500 Ω



This product is covered by a limited lifetime manufacturer warranty.

Although we are not authorised to determine if any repair is covered under warranty, if the item was purchased through World of Music, then we are often the best people to facilitate the claim for you and will do so as timely as possible. Warranty does not apply to cosmetic damage or faults that are a result of user neglect. Although your mate is really handy with a soldering iron, any product modification or home repair will also result in a void warranty.

Quite often, something perceived as a fault is as simple as a faulty cable or power issue so we always suggest checking over Frequently Asked Questions on the manufacturer website first. It can be a helpful approach to getting to the bottom of a problem and save you a lot of time in getting your gear back up and running!

This item ships via courier; fully insured for your peace of mind. Orders require a signature on delivery and we suggest using an address where someone will be present for the speediest delivery time. For delivery attempts with no one present to sign, your order will be taken to the courier depot and a card will be left for you to organise redelivery.



Product Description
The Organizer is a polyphonic organ emulator designed to mimic the organ tones of yesteryear crossed with the highly unique "Guitorgan”. The organizer has a warm and very analog  feel with a hint of Leslie warble that is unlike other modern  octave shifters. It tracks all over the neck on both guitar and  bass and will transpose single notes as well as chords. The  Organizer uses a mix of analog and DSP circuitry with true bypass switching and an all analog direct (dry) signal path. Controls Up: Level control for the octave up. Down: Level control for the octave down. Choir: This control takes a mix of the octave up and octave down setting and regenerates it. The end result is an additional 2 octaves up, 2 octaves down and direct signal with a slight delay that adds a "church organ” like feel. This control only works if the octave up and octave down are in use. Direct: Level control for the analog dry signal. Tone: Low pass filter for the wet signal, counter clockwise rolls off the high end. Lag: Delay control for the wet signal. Full counter clockwise is minimal delay, delay time increases as it rotates clockwise. Power A standard 9 volt DC power supply with a negative centre 2.1mm barrel, current draw is 70ma. No battery option. Measures 4 5/8" x 2 1/2" x 2.25" with knobs Notes The Organizer has an output gain stage with no master control. When it's idle, even with all knobs at zero, the will be about as much "white noise" as an average overdrive pedal with it's gain at zero and the level set to unity. A minimal amount while idle is normal but it will not be noticeable during play. The sound will be more apparent in front of a gained up amp or other dirt/gain/boost pedals.
Specifications

Switching
This device is true bypass and uses electronic relay-based switching. Audio will not pass without power.

Power
This device takes a standard 9 volt DC power supply with a 2.1mm negative centre barrel. We always recommend pedal-specific, transformer-isolated wall-wart power supplies or multiple isolated-output supplies. Pedals will make extra noise if there is ripple or unclean power. Switching-type power supplies, daisy chains and non-pedal specific power supplies do not filter dirty power as well and let through unwanted noise. DO NOT RUN AT HIGHER VOLTAGES!Dimensions: 4.75 x 2.50 x 2.25 in. (121 x 64 x 57 mm) with knobs
Current Draw: 81 mA
Input Impedance: 1 MΩ
Output Impedance: 500 Ω
